Description
Power ：
700W@220V
LED light source：
Strobe Tube LEDS
LED Type: 3535 5W 6500K LEDs
LED Count: 144
LED Colors: Cool-White
LED Segments: 16
Strobe Panel LEDs
LED Type: 5050SMD 2W RGBW 4 in1
LED Count: 242
LED Colors: Cool-White
LED Segments: 32 (2x16)
Working lifetime
50000h
Dimmer ：
0-100% linear dimming
Strobe ：
Electric strobe，0.3-20pcs/sec Max 20 Hz
Control mode：
13CH/89CH/64CH,20CH/4CH(Art-net)
International standard DMX 512signal，3 Pin (5 Pin) DMX512 interface RDM
Wireless ：2.4 GHz W-DMX™ (optional)
Art-Net ： (optional)
3 channel modes
Master-slave
Stand-alone mode
Self-test modeOtherfunctions：
Adjustable horizontal and vertical speed
Display fixture using time
Display software version number
Modular structure for easy maintenance
Speed-regulating radiator
Connector
Power : Seetronic Powercon Ture1
DMX: Seetronic XLR Cable Connector
Art-net : Seetronic RJ45 Connector
Shell and protection level：
High-strength casting aluminum alloy，IP66 black shell（white optional）
Working temperature：
-20°C～40°C
Weight：
8.9 Kg
