Description
Power Supply
Electronic supply with active PFC
AC100-240V 50/60Hz
180W Power consumption
Light Source
18 x 10W 4in1 LED, RGBW
Flicker free operation for
broadcast TV and FILM
Life Span: 50000H
Optics
High efficiency acrylic lens
25°/45°Lens(35°/55°Field angle)
LED pixel control
coverage with pure mixing
Preset color macros
Strobe Effect
0-25Hz high speed shutter/strobe effect
with variable speed
Dimming System
0-100% Smooth linear LED dimming
Control System
4/8/12channels USITT DMX-512
DMX512, master-slave, sound activated or
auto operation
Multi preset internal programs
DMX recorder and edit function integrated
Shielded input signal protection for stable
signal without interference
IP65 3-Pin XLR cables IN/OUT
Display System
LED display
4 Control buttons
Display auto OFF
Cooling System
Advanced cooling
system integrated aluminum
Housing
Skeleton made of aluminum and steel
metal plates
Tilt angle manually adjustable
Exterior finish: Black
Installation
Two hanging points on the base
1*Safety attachment point
Operating Condition
Operating positions:
all (device on floor or fixed to a support)
-25℃ to 45℃ ambient temperature
IP65 protection rating
Weight& Size
N.W.: 7kg
G.W.: 8kg (Carton packing)
G.W: 94.5KGS (Flycase packing)
Light Size:110x18x16cm
Packing Size:116x51x74cm Flycase
