Description
Light source:
Colored light: 672 x 0.5W RGB LED
White light: 112 x 3W CW LED
Power: 420 W
Beam angle:
Colored light beam angle: 101°
White light beam angle: 108°
Beam angle:
Illumination spot angle: 149°
White light spot angle: 152°
The 32 zones of colored light can be controlled individually
16 white light zones can be controlled individually
Excellent color mixing capabilities
Powerful and high-output strobe effect
Built-in splicing pins enable quick splicing and alignment
Electronic atomization effect
0-100% smooth dimming function
Optical system
Efficient optical system
controls and procedures
4 touch buttons
Control protocol: DMX512,RDM,Art-Net,sACN
DMX channel mode: 11CH, optional 7/15/21/39/112/17/33/65/68/117/70CH
Software upgrade: Update software via DMX connection
Lamp specifications
Length: 1,000mm (39.4")
Width: 139 mm (4.9")
Height: 90 mm (3.5")
Lamp net weight: kg (19 lbs)
Carton Size
Length:1100 mm (42.7")
Width: 195 mm (7.7")
Height: 320 mm (12.6")
Weight: 10.5 kg (23 lbs)
working environment
Maximum ambient temperature: 40°C
Minimum operating temperature: -10°C
Maximum surface temperature: 65°C
Protection level: IP66
