Electrical
Input Voltage: AC200-240V 50/60Hz
Input Power: 1800W, PF≥0.98
Maximum input current: 9 A
Light Source
Light source: OSRAM Lok-it 1400-PS_Brilliant
Color temperature: 6000 K
Expected lifespan: 750 Hours
Optics & Photometric Data
Reflection bowl: Europe imported reflection bowl, primary and secondary reflection bowl design
Front lens: 3 sets of premium optical components with anti-reflective film, diameter of front lens: 160 mm
Total luminous flux output ≥ 36000lm
CRI (Color rendering index): Ra ≥ 95, R9 ≥ 90
Uniformity rate: ≥ 80%
Electronic auto-tracking zoom range: 7°~ 50°
Color System
CMY infinite color mixing system, the color (RGB) system has high color saturation, high pureness and high brightness
CTO color temperature, 3200K-6000K linear adjustment
One static color wheel, 7 color filters + open, color rainbow rotate in both directions, stepping, sliding gradient, random color mode
Gobo System
One rotate gobo wheel, 5 rotation in both directions and positionable gobo plates, rotation, water flow, shake, gobo wheel 16 bit controllable
One static gobo wheel, 9 gobo plates plus open, water flow rotate in both directions
One animation wheel, cloud, flame and water flow etc. effects
Framing System
One complete framing system, 4 x individually controllable curtain blades with variable angle of 90° through the entire insertion path; it only takes 0.2 second for the entire rotation path
Effect Equipment
One rotate 4-facet prism with rotation in both directions
Dual frost filters, linear, uniform and high brightness output
Dimmer: independent 0-100% dimming control, multiple choice of dimming curves
Mechanical fast strobe, with speed adjustment from 0.8 to 15 flashes per second, multiple strobe options: pulse, synchronous, asynchronous, random slow, medium and fast speed
High speed motorized iris 5-100% linear adjustment, built-in multiple macro functions
Fixture Movement Parameters
PAN=540° – 16 bit
TILT=270° – 16 bit
Control and Programming
DMX Channels: 32 Ch/ 35 Ch/ 56 Ch
Control Protocols: DMX512, RDM; Art-Net, sACN, wireless function (optional)
Control Portals: XLR-3; RJ45 (optional)
Menu display: 3.5” color LCD touch screen; choice of Chinese and English language, menu available to be displayed 180° reversely
Built-in self-rechargeable battery, menu can be edited without power supply (optional)
Eco mode (sleep mode when standby)
Electronic sensors testing, fan intelligent detection and control
Non-touching magnetic encoder positionable system for pan-tilt
Size & weight
Fixture size: (472X472X807) mm
Road case size: (710X550X865) mm (1 position)
Road case net weight: 30 KG
Fixture net weight: 48 KG
Working Conditions
Working environment temperature: -20℃~ 40℃
Protection rate: IP 20
