Power:
Input Voltage: AC200-240V 50/60Hz
Input Power: 1800W, PF≥0.98
Maximum input current: 9 A
Light Source:
Light source: 1600W White LED module (choice of high brightness mode and high CRI mode)
CRI (Color rendering index): Ra≥ 70 (high brightness); Ra≥ 90 (high CRI)
LED expected lifespan: 20000 Hours
Optics :
Frontal lens: High-definition lens with anti-reflective film
Zoom range: 5°~ 50°
Color System
CMY infinite color mixing system, the color (RGB) system has high color saturation, high pureness and high brightness
CTO color temperature, 3200K-6200K linear adjustment
One color wheel, 7 color filters + open, rotate in both directions, color rainbow， stepping, sliding gradient, random color mode
Gobo System
Two rotate gobo wheels, 6 rotate in both directions and positionable gobo plates, rotation, water flow, shake, 16 bit control
One animation wheel, continuous rotate to create cloud, fire and water flow effects
Framing System
One complete infinite rotatable framing system, 4 x individually controllable full curtain blades with full variable angle through the entire insertion path. No distortion, precise locating, infinite rotation
Effect Equipment
Two prisms with rotation in both directions, overlayable, follow focus
Two frost filters, overlayable, follow focus
0-100% dimming control, 4 choice of dimming curves, 4 choice of dimming speeds
Electronic strobe, with speed adjustment from 1 to 25 flashes per second, multiple strobe options
High speed motorized iris 5-100% linear adjustment, built-in macro function
Fixture Movement Parameters
PAN=540° – 16 bit
TILT=270° – 16 bit
Electronic Control Technology
DMX Channels: 37 Ch/ 40 Ch/ 60 Ch
Control Protocols: DMX512, RDM, Art-Net, sACN, wireless function (optional)
Control Portals: XLR-3; RJ45 (optional)
Menu display: 3.5” LCD color screen; choice of Chinese and English language, menu available to be displayed 180° reversely
Built-in self-rechargeable battery, menu can be edited without power supply (optional); support connecting power bank to enter the menu and edit address code and other settings
Electronic sensors testing, fan intelligent detection and control
Eco mode (sleep mode when standby)
Non-touching magnetic encoder positionable system for pan-tilt
Size & weight
Fixture size: (470 X 470 X 894) mm
Road case size: (760 X 550 X 890) mm (1 position)
Fixture net weight: 49KG
Road case net weight: 34KG
Working Conditions
Minimum and maximum ambient temperature: -20℃~ 40℃
IP20
