Description
Power supply:
LED Source:
Light source: 1000W LED module
LED life: 20,000 hours
Color temperature: 7000K
Luminous flux: 48000LM
Optical System:
Lens: 138MM
CRI: standard mode Ra>73, high display mode Ra>90
Color:
Colors: 7 colors
Color mixing system: independent CMY color mixing system
Color temperature adjustment: independent CTO 2700-7000K linear adjustment
Gobo:
Animation wheel: Stunning simulation of dynamic flames, gurgling water and other dynamic effects
Fixed GOBO: 9 fixed GOBOs + white circle
Rotating GOBO: 6 GOBOs (pluggable) outer diameter 27.9mm, effective diameter 16.5mm, thickness 1.1mm
Control Mode:
Signal interface: Standard 3pin and 5pin XLR socket
cONControl mode: DMX512, RDM, self-propelled, master-slave, voice control
Channel mode: 36CH,DMX512 channels
Effect:
Prism: rotating 3 facet + 6facet linear prisms
Cutting system: 4 independent cutting blades, each blade can be individually closed and rotated 90°
Atomization system: 0~100% linear atomization
Aperture system: 5%~100% smooth adjustment
Zoom system: 4.5°~50° linear zoom
Dimming system: 0-100% linear adjustment
Strobe system: the frequency can reach up to 25Hz, and random strobe and pulse strobe can be selected. Horizontal scan: 540° (16bit precision scan)
Vertical scanning: 270° (16bit precision scanning)
XY: Using five-phase motor with magnetic encoding positioning function
Display system: 2.7-inch touch LCD display, Chinese and English display, 180-degree rotation
IP Rate: IP20
Size& Weight:
Product size: 385*270*690(mm)
Carton size: 745*705*615mm
N.W: 33kg, G.W: 41.3KG
Flycase size: 950*580*830mm, G.W: 96kg
Product appearance: flame retardant, high temperature resistance, foldable integrated light hook
