Power Supply：100~240V，50/60Hz
Power：950W (90V), power factor: PF ≥ 0.98
LED source：700w LED module (rated life of bulb: 20000h)
Color temperature：7500K
Optics: zoom 4.5°-50°
Spot uniformity 90%, color rendering index:800≥70/800H≥90
Color system: CMY+CTO Color mixing system
Color Wheel：1 color wheel, 6 colors plus white, half-color effect, color film can be positioned arbitrarily, with rainbow effect of bidirectional rotation.
1 fixed gobo wheel, 8 goboes plus white circles;
1 rotating goboes wheel, 6 patterns plus white circles;
Self charging buffer battery, no power state Edit menu.
Fan intelligent control, temperature electronic sensor detection.
DMX channel level monitoring, LCD screen lamp information query, RDM data two-way transmission.
Non contact magnetic rotary encoder positioning, signal feedback, absolute position memory, offline power off position recovery.
Fixture Movement：
PAN 540°, Accuracy 2.11°/ Step, fine tuning accuracy 0.008 °
TILT 270°,The accuracy is 1.05°/ Step, fine tuning accuracy 0.004 °
Horizontal and vertical non-touch magnetic rotary encoder positioning reset system.
with automatic error correction.
Effect equipment:
Fast motorized iris 5-100% linear adjustment, with macro function and multi-effect change Electronic
dimming, 0-100% linear dimming, uniform light spot
The electronic stroboscopic speed is 1-25 times/sec. You can choose pulsation, asynchronous, synchronous, random slow, medium, fast, etc
Prism: 4 facet Prisms+ Six-sided gradient mirror；
It can be rotated and superimposed in both directions, and has a prism positioning function.
Profile: 4 gratings realize fast and smooth cutting, each grating can be individually controlled in cutting and degree;
Single light can be turned off completely, and the whole module can be rotated ±45°.
Control:
Standard DMX512 protocol, Art-net Ethernet control protocol, SACN protocol and wireless DMX512 control (optional)
IP Rate:
IP 66
Size& Packing:
N.W: 29.8Kg, G.W (carton): 34Kg
Light Size:690×400×500mm
Packing size (carton):520×420×420mm
