Description
LED Source
Light source type: Tungsten LED bulb
Base: E27
Recommended lamp type
LV-40W-A: Bell 60021 LED Vintage Soft Coil Filament 125 mm Large Globe ES Cap 4W
LV-40W-B: Bell 60019 LED Vintage soft coil filament 95 mm Globe ES Cap 4W
Lifetime: 15,000 hours
Colour temperature: 2200 K
Optical System
LV-40W-A: 496mm see through parabolic aluminium reflector with gold-brown coating
LV-40W-B: 353mm see through parabolic aluminium reflector with gold-brown coating
Control and Programming
External Dimmer
Thermal Specification
Maximum ambient temperature: 45°C (113°F)
Maximum surface temperature: 160°C (320°F)
Electrical Specification and Connections
Input voltage range: 120 V or 240 V, 50/60 Hz
(The default voltage is 240V and needs to be changed to 120V. Please specify in the order)
Power consumption: 4 W
Mechanical specification
LV-40W-A
Height: 639.7 mm
Width: 684.9mm
Depth: 166.5 mm
Weight: 7.2 kg
LV-40W-B
Height: 491.2 mm
Width: 529.08 mm
Depth: 139.2 mm
Weight: 4.8 kg
Ingress protection rating: IP20
Rigging
Mounting points: M12 mounting for clamp or spigot
Universal operating position
