Description
Strobe Panel LEDs
LED Type: 5050 0.5W RGB 3in1 LEDs
LED Count: 640 LED Colors: RGB
LED Segments: pixel
Strobe Tube LEDs
LED Type: 3535 5W 6500K LEDs
LED Count: 144
LED Colors: Cool-White LED Segments: 8
Control
Control Modes:11CH / 136CH / 5CH (net) / 12CH (net)
Display: OLED
Protocol: USITT DMX-512, RDM,ART-NET
RDM: Bidirectional communication
Wireless DMX: 2.4 GHz W-DMX™ (optional)
Cooling: Temperature controlled, overheating protection
Effects
Dimmer: 0-100% electronic Shutter: electronic, max. 20 Hz Internal Effects: LED Macro Effects
Connectors
Signal connection: Seetronic IP65 XLR 5-Pin or 3-Pin In/Out Power Input: Seetronic powerCON TRUE1 In/Out
Operating Condtions
Mains voltage: 100-240V AC / 50-60Hz
Power: 1200W
Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F Operating Position: any
Mounting Options Standing: Rubber feet Hanging: Omega-Bracket
Safety wire attachment: foldout eyelets
Shipping
Single fixture: cardboard (inner and outer cartons) Tourpack: 4-way Flight Case
Housing Colors
Standard colors: black
Weight
N.W: 14 kg
G.W: 15.5 kg
