Description
Mains voltage: 100-240V AC / 50-60Hz
Power: 1200W
LED Sourcew: 40x 20W RGBW
RGBW：（54%） 765W
R：337W, G：365W, B：377W, W：375W
LED Segments: 10 (2 x 5)
Movement: Tilt (Degrees): 185°, 8-16 Bit
Control Modes: 12CH /43CH / 49CH /5CH
Display: Illuminated graphic OLED
Protocol: USITT DMX-512, RDM
RDM: Bidirectional communication
Wireless DMX: 2.4 GHz W-DMX™ (optional)
Cooling: Temperature controlled, overheating protection
Dimmer: 0-100% electronic Shutter: electronic, max. 20 Hz Internal
Effects: LED Macro Effects
Connectors
Signal connection: Seetronic IP65 XLR 5-Pin or 3-Pin In/Out Power Input: Seetronic powerCON TRUE1 In/Out
Operating Condtions
Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F Operating Position: any
Mounting Options Standing: Rubber feet Hanging: Omega-Bracket
Safety wire attachment: foldout eyelets
Size & Weight:
Length: 502x 137 x326 mm
N.W: 12.2 kg, G.W: 13.8 kg
