Description
Rated voltage: AC100～240V/50～60Hz
Power: 350W
Light source: 260W laser module
Color temperature: 6500K
Expected service life of LED: 12000 hours (data provided by light source supplier)
Effect
Optical angle: 0.6-28°
Prism: 2 prism wheels, 8 prism effects, can be superimposed to produce multi-layer beam effects, can be rotated in both directions, and has prism
positioning function
Dimming: 0-100% linear dimming
Strobe: 1-25Hz fast strobe, pulse strobe, synchronization, random slow, medium, fast and other modes can be selected
Atomization: 1 light atomization, 1 heavy atomization, atomization superposition can be done
Color system
CMY infinite color mixing system
1 color wheel, 19 fixed colors plus white, with bidirectional rotating rainbow effect, arbitrary positioning function
GOBO system
1 rotating pattern wheel: 12 GOBOs + white circle, easy to replace, with pattern jitter, arbitrary positioning function
1 fixed pattern wheel: 35 GOBOs + white circle, with pattern jitter and forward and reverse scrolling, arbitrary positioning function
Control and software
4 touch buttons
Control panel: LCD display
Protocol: DMX512, RDM
2 channel modes: 22CH/27CH
Scanning movement
Horizontal: Support 0-540° (16 bit precision scanning), can rotate continuously at the same time
Vertical: Support 0-270° (16 bit precision scanning), can rotate continuously at the same time
X-axis/Y-axis position out of step automatic correction
Working environment: -10°C- 65°C
IP rate: IP66
Size & weight:
Size: 397.5mm*280mm*693mm
N.W: 31KG, G.W: 35KG
