Description
Rated voltage: AC100~240V 50/60Hz
Power consumption: ≤100W
Scanner: 25kpps , scan angle:max±30°; Input signal:±5V;Linearity distortion<2%
Motor: 3 phase 42 motor 2pcs
X axis 540° rotation,Y axis 270° rotation
Modulation: analog
Beam diameter and divergence: 3*6.5mm; 1.5mrad
Control mode: music (black out)/ automatic/master-slave/DMX512(6/40CH)/ILDA
Control interface: 3 pin DMX512/25DB ILDA
Demonstration effect: built-in 140 pattern and 5 pages of animation
DMX effect: Single pattern mode, and with the function of unique blanking, strobe,
rotation, movement, billowing, zoom, write in, speed and color etc.
Operating requirement: dry, less dust, 0~35℃(environmental temperature), will reduce the attenuation of the diode and extend the life of the light.
Application: disco, club, concert, medium indoor venue, festival
Carton size: 34.5*23*48cm
Gross weight: 9.5 kg
2in1 Flight case size: 66*46*65cm
Gross weight: 41kg
