Light Source：SIRIUS HRI® 371W S
Color temperature：7500K
Light source life：≥1500hours
Electrical parameters
Voltage: AC90-264V, 50/60Hz
Power: 530W (90V)
Optical system
Light Source：SIRIUS HRI® 371W S
Color temperature：7500K
Light source life：≥1500hours
Color system
1 color wheel: 11 color each + white,
half-color effect, rainbow effect with
bidirectional rotation.
Gobo system
1 fixed pattern plate: 14 pattern pieces +
white, with pattern dithering and pattern
arbitrary positioning function.
Prism system
Prism 1: 8prisms.
Prism2: 24 prisms.
Prism3: Colorful rainbow prism
2 prisms can be stacked
Effect
Focusing angle：1.8°
Atomization：
Independent atomization
Dimming：0-100% linear dimming.
Strobe: up to 25Hz, can choose random
strobe or pulse strobe.
Display
Display: Rechargeable battery, you can enter
the menu to set without powering on. The
Chinese and English languages can be
switched, and the display can be reversed 180°,
which is convenient for hanging upside down.
Reset detection: When there is no DMX signal,
manual detection and automatic detection can
be selected to facilitate inspection and
maintenance.
software
9 built-in programs to choose from
Upgrade via DMX data cable
Can change the DMX address code from the
console, remote control switch bulb, machine
reset and other functions
Display lamp and light source usage time
2 channel modes:16/13 channels
Control
High temperature automatic protection
Standard DMX512 protocol
DMX shortcut interface
RDM function
Scan
X:540°（16 bit precision scan）
Y:270°（16 bit precision scan）
Automatic error correction reset function
Environment
IP20
-10℃- 45℃
Size and Packing:
Product Size：618*422*301mm
Packing size (carton)： 730*430*540
Net weight: 21.6kgs
Gross weight (carton): 25.7kgs
