Description
Smart control system:
Camera parameters: 20x zoom, 5 million pixels,
The total number of channels of the supporting control software is 240way
Number of controllable computer lights: 12pcs
Maximum number of channels for controlling computer lights: 16 channels
Number of program games: 12 games
The total number of steps in the program: 480 scenes
Scene pause time 0.1-25.5/step
Scene gradient speed 0.1 to 25.5/second
Display 10-inch LCD display
DMX512 output interface 3pin XLR
Storage capacity: 128K large capacity memory card,
The joystick controls the shaking of the head up, down, left, and right.
The console can set the positive and negative directions of the XY axis at any time.
The joystick has speed adjustment, real-time monitoring of the screen, and convenient operation.
Light Total power: 1200W
110V-240V,50Hz-60Hz
Light source: LED1000W
Color: 5 colors, white light, red, yellow, blue, green, rose red, CTO 3200K-4500K-5600K-6500K + atomization effect, gradient available
Function: Stepless linear electronic focusing; open light and closed light + 0-100 linear dimming.
2 color palettes. Strobe-aperture size electronically adjustable + automatic size function
Horizontal/vertical: Customized three-phase motors are used for horizontal and vertical. It can rotate 540° horizontally and 210° vertically. The speed is fast and stable. The light is equipped with an intelligent photoelectric reset and correction system. If it accidentally malfunctions, it can automatically recover. original location.
Channel: 16CH
Beam angle: 5-30 degrees
Projected light distance: 120-200 meters
Flycase size: 530X430X320mm weight 23KG
Light: 650×580×980mm
N.W: 38.5kg, G.W: 42.5kg
