Voltage: AC90V-240V, 50/60Hz
Power: 550W
Light source: Osram 470W , life time 1500H
Color temperature: 7700K
Zoom angle: 7.2°~34° (pattern mode)
Power:
Voltage: AC90V-240V, 50/60Hz
Power: 550W
Light source: Osram 470W , life time 1500H
Optics:
Color temperature: 7700K
Zoom angle: 7.2°~34° (pattern mode)
Linear dimming: double-chip mechanical dimming, linear dimming 0~100%.
High-speed stroboscopic: Double-sided channel stroboscopic, multiple speed stroboscopic effects.
Atomization: 0%-100% atomization
Color system:
Color plate: 3 color plates: each 4 color plates + CMY + white light, any color gradient effect, with two-way rotating rainbow effect.
The colors of the 3 color plates can be superimposed arbitrarily to create infinite dynamics and infinite color changes.
Gobo system:
Gobo plate: 1 fire plate: independent flame effect 1 fixed pattern plate: 13 patterns + white circle, with pattern jitter and pattern arbitrary positioning function.
1 rotating gobo wheel: 8 gobos + white circle, with pattern jitter and pattern arbitrary positioning function
Prism:
Prisms plate: prism 1- 8 prisms. prism 2- 16 prisms,2 prism discs can be superimposed to create infinite dynamics and infinite beam effects.
Horizontal/Vertical:
Horizontal scanning angle is 540°, vertical scanning angle is 270°, the speed of horizontal/vertical movement can be adjusted
Automatically complete horizontal/vertical correction Optocoupler positioning function for easy initial position correction and maintenance.
Vertical locking function to prevent damage to the lamp during transportation.
Low noise/large torque, stable operation, extremely fast response: X-axis horizontal scanning speed is 2.2 seconds, Y-axis horizontal scanning speed is 1.0 seconds.
Display:
LCD liquid crystal display in Chinese and English, beautiful, simple and convenient to use. Built-in Ni-MH battery can control the system normally when the power is off
Cooling system: adopts one-in-one-out design, cooling fan, and dustproof window for cooling.
Control:
Control channel: 26/30 channels are optional, DMX, wireless control (optional), RDM, update software through DMX connection
Lamp connection: 3-pin signal line input and output and the first fast in-line DMX signal interface, power input
Index function and 16Bit precise fine-tuning.
Communication design: equipped with DMX three-core transmission and direct transmission signal interface
Environment
IP20
-10℃- 45℃
Size and Packing:
Light packaging: waterproof and shockproof air box or carton.
Light size: 618 x 422 x 301mm
Packing size (carton): 730 x 430 x 540mm
Net weight: 24.5kgs
Gross weight (carton): 28.6kgs
