470w beam
Osram SIRIUS HRI ® 461W
Optical system
Voltage: AC90V-240V, 50/60Hz
Total power rate: 530W
Light source: Osram 461W bulb, lifespan 1500H
Color temperature: 7700K
Zoom angle: 0-1.8°
Linear dimming: double-chip mechanical dimming, linear dimming 0~100%.
High-speed stroboscopic: double-sided channel stroboscopic, multiple speed stroboscopic effects
Atomization: 0%-100% atomization
Color system
Color plate: 1 color plate: 11 color plates + white light, any half-color effect, rainbow effect with two-way rotation.
Gobo system
Gobo plate: 1 fixed gobo plate: 14 gobo pieces + white circle, with pattern jitter and pattern arbitrary positioning function.
Prism system
Prism disc: disc one 8 prism. disc two 24 prism. disc three: colorful prism, 2 prism discs can be superimposed and used to create infinite motion and infinite beam effect.
Index function and 16Bit precise fine-tuning.
Communication design: equipped with DMX three-core transmission and direct transmission signal interface
Scan:
The horizontal scanning angle is 540°, the vertical scanning angle is 270°, and the speed of horizontal/vertical movement can be adjusted. The horizontal/vertical correction photocoupler positioning function is automatically completed, which is convenient for initial position correction and maintenance. Vertical lock function to prevent transportation The lamp is damaged in the process, low noise/large torque, stable operation, extremely fast response: X-axis horizontal scanning speed is 2.2 seconds, Y-axis horizontal scanning speed is 1.0 seconds.
Display
LCD liquid crystal display in Chinese and English, beautiful, simple and convenient to use. Built-in Ni-MH battery can control the system normally when the power is off
Heat dissipation system: adopts one-in-one-out design, cooling fan, and heat dissipation window to prevent dust
Control
High temperature automatic protection
Standard DMX512 protocol
DMX shortcut interface
RDM function
Environment
IP20
-10℃- 45℃
Size and weight
Product size: 618*422*301
Packing size (carton): 730*430*540
Net weight: 21.6kgs
Gross weight (carton): 25.7kgs
