AC100-240V 50/60Hz
461 BEAM RP: input power: 691W, PF≥0.98
Light Source
Lamp model: 461 BEAM RP: OSRAM SIRIUS HRl® 461W
Optics System
Lens: high-efficiency antireflection coating lens, Φ200mm
Beam angle：2°
1 fixed color wheel with 11 color filters + white;
Bi-direction rainbow, stepping, gradual changing color, random color mode.
Gobo System
1 fixed gobo wheel with 18 gobo +white；
Make water running, and shaking effects；
1 animation wheel
Effect equipment
2 prism effect wheel with 6 prism, overlaid and bidirectional rotation;
Independent frost effect;
0~100% mechanical linear dimmer.
Movement Parameter
PAN=540°, speed: 540°/2.5s 16bit precision adjustment;
PAN=260°, speed: 260°/1.5s 16bit precision adjustment.
Electronic Control Technology
Channel: 18Ch/22Ch/26Ch
Control protocol: Standard DMX512, Art-net & wireless DMX512 (optional);
LCD display: 2.4 inches LCD color screen; Random switch of Chinese and English, menu available to display 180°reversely;
Non-touch roller operation mode;
Power auto-reduction when closed. Energy conservation, environmental protection;
Fan intelligent controlled, Electronic sensors testing;
DMX channel level monitoring;
RDM
Physical Parameter
Fixture size: 456X306X689{mm)
Net weight: 33.5Kg
IP rate: IP55
